DIN-rail AC/DC power supply
A DIN-rail power supply converts an input supply into a specified DC auxiliary supply.
General arrangement objects
General arrangement objects · PSC 241
Altech PSC-241 power-supply housing
Mechanical housing reference for PSC-24124 and PSC-24148 supplies.
In plain English
What does Altech PSC-241 power-supply housing mean?
Locate the supply on the panel rail with clear access to incoming power and outgoing DC terminals. Keep adjustment and indication visible in the installed position.
A simple example
Use altech psc-241 power-supply housing to identify the role shown at this point in the drawing. The CAD register groups the 24 V and 48 V order codes under PSC-241 geometry.
What the drawings help you do
The mechanical housing name is not a complete purchase specification. Read the symbol, label and connected lines together. The reference illustration explains a concept; the selected equipment's documents supply actual terminal details, dimensions and ratings.
This particular reference
Mechanical housing reference for PSC-24124 and PSC-24148 supplies. The mechanical housing name is not a complete purchase specification.
- DC
- Direct current: electricity flowing in one direction.
- Normally open / normally closed
- The contact state in the normal condition defined for the drawing.
- Terminal
- An identified point where a conductor connects.
Read the source: Altech PSC-241 power-supply housing official drawing source
Explore the model in 3D
An original 3D illustration of this equipment type. Rotate and zoom to explore its shape. It does not represent an exact manufacturer model or dimensional layout.
Altech PSC-241 power-supply housingIllustrative 3D · Not to scale
Drag to rotate · Scroll or pinch to zoom · Original educational visualisation. Relative proportions; use the selected manufacturer drawing for dimensions.
What it represents
Locate the supply on the panel rail with clear access to incoming power and outgoing DC terminals. Keep adjustment and indication visible in the installed position.
The downloadable GA illustration is independently authored conceptual geometry, with no scale or manufacturer dimensions. Use the official CAD source for the exact layout.
Altech originals remain at the manufacturer source because their drawing notices restrict reproduction. Product lifecycle and availability have not been established.
How to read it
- The CAD register groups the 24 V and 48 V order codes under PSC-241 geometry.
- The mechanical housing name is not a complete purchase specification.
Information to show or reference
- Record PSC-24124 or PSC-24148.
- Coordinate mounting orientation and wire-entry space.
- Confirm present availability and required spacing.
A distinction that matters
The mechanical housing name is not a complete purchase specification.
Sources you can follow
These public references support the explanation and provide further detail. Their graphics and downloadable files remain with their publishers.
Altech PSC-241 power-supply housing official drawing source
Manufacturer identity and available drawing route; exact file identity is recorded in the linked CAD entry.
