Understand the difference.

Compare the meaning, drawing context and source references of two entries. A similar graphic or shared abbreviation does not establish equivalence.

Deckel-DK-01xx

General arrangement objects

Hensel Deckel-DK-01xx enclosure lid

Deckel-DK-01xx is the drawing identifier for enclosure lid in Hensel's ENYCASE enclosure and distribution-system STEP collection. An enclosure lid closes the selected enclosure base. Its removal or opening space, fixings and any attached equipment need to be coordinated separately from the base.

Drawing use

GA

Application

Equipment layouts

Reference family

Manufacturer

A distinction that matters

This reference concerns the named Deckel-DK-01xx drawing and its enclosure lid role. A drawing in the same collection is not automatic evidence of compatible terminals, mounts or electrical performance.

Full referenceAdd to legend

GA

General arrangement objects

Wall-mounted junction enclosure

A junction enclosure houses the specified wiring connections at a field location.

Drawing use

GA / SLD

Application

Equipment layouts

Reference family

Manufacturer

A distinction that matters

Enclosure outside size differs from usable internal mounting space.

Full referenceAdd to legend

Follow the full entry for source drawings and the appropriate standard or selected product. Equipment previews show a manufacturer drawing where available, otherwise a 3D thumbnail.
