Side-by-side reference

Understand the difference.

Compare the meaning, drawing context and source references of two entries. A similar graphic or shared abbreviation does not establish equivalence.

First referenceCompare with

KN-10J10

General arrangement objects

AutomationDirect KN-10J10 terminal jumper

KN-10J10 is the drawing identifier for terminal jumper in AutomationDirect's Konnect-It DIN-Rail Terminal Blocks collection. A terminal jumper makes a selected common connection between compatible terminal positions. Its mechanical reach and the positions connected must be checked against the actual terminal system.

Drawing use: GA
Application: Equipment layouts
Reference family: Manufacturer

A distinction that matters

This reference concerns the named KN-10J10 drawing and its terminal jumper role. A drawing in the same collection is not automatic evidence of compatible terminals, mounts or electrical performance.

Full reference

General arrangement objects

Feed-through terminal block

A feed-through terminal provides a defined wiring connection across a terminal position.

Drawing use: GA / Schematic
Application: Connections & wiring
Reference family: Manufacturer

A distinction that matters

Its rail mounting and conductor capacity are product-specific.

Full reference

Follow the full entry for source drawings and the appropriate standard or selected product. Equipment previews show a manufacturer drawing where available, otherwise a 3D thumbnail.
