ZP-MC03A-1-FC005

General arrangement objects

AutomationDirect ZP-MC03A-1-FC005 connector insert

ZP-MC03A-1-FC005 is the drawing identifier for connector insert in AutomationDirect's ZIPport Multi-Wire Connectors collection. A connector insert carries the selected connection interface within its compatible housing. The insert drawing does not describe the complete housing, hood or cable restraint.

Drawing use

GA

Application

Equipment layouts

Reference family

Manufacturer

A distinction that matters

This reference concerns the named ZP-MC03A-1-FC005 drawing and its connector insert role. A drawing in the same collection is not automatic evidence of compatible terminals, mounts or electrical performance.
